Whelen MCRNSC - 01-066G281-30C

MCRNSC
Whelen
Lighthead MCRNSC
Brand Whelen
SAE Class 1 Certified
Certs T13
Lens Color Clear
LED Color White
Mount Surface
Cable 6" Pigtail
Housing Color Black
Volts 12 VDC

$95.70

Options
MCRNB1 - Black angle "L" mounting bracket, Micron Series $12.94
MCRNB2 - License plate bracket for 2 lights, Micron Series $29.95
At just over 4” wide, Whelen’s compact Micron Series lightheads are designed for use in virtually any lighting application. This unit meets or exceeds SAE J845, SAE J595, KKK-1822F, and California Title XIII specifications. This also has a 5 year warranty.
Prop 65 WarningWARNING: This product may contain chemicals known to the State of California to cause cancer, birth defects and/or other reproductive harm. See more information at https://whelen.com/regulatory
Specifications for 01-066G281-30C Whelen MCRNSC Replacement Lighthead
GENERAL CHARACTERISTICS
Lens Color Clear
LED Color White
Mount Surface
Flash Pattern 25 Scan-Lock™
Technology Super -LED
SAE Class 1 Certified
Certs T13
ELECTRICAL CHARACTERISTICS
Volts 12 VDC
Amps 0.6
DIMENSIONS
Height 0.875in (23.00mm)
Width 4.00in (102.00mm)
Depth 0.875in (23.00mm)
PRODUCT INFORMATION
Product Code 01-066G281-30C
Series Micron
Description MCRNSC
SKU Qty 1
Sales Unit Each
Whelen MCRNSC 01-066G281-30C Replacement Lighthead Applications & Features

Features

  • 25 Scan-Lock™ flash patterns, including steady-burn
  • Directional light pattern
  • Hard-coated lenses minimize environmental damage from sand, sun, salt, and road chemicals
  • Surface mount models include flange
  • Synchronizable to other Whelen sync products
  • Supplied with a 6” 4-wire pigtail
  • Meets or exceeds SAE J845, SAE J595, KKK-1822F, and California Title XIII specifications
  • Five year warranty
Literature for the Whelen MCRNSC 01-066G281-30C Replacement Lighthead

PDF IconMicron Series Product Sheet
PDF IconMicron Series Installation Guide
Warranty information for the Whelen MCRNSC 01-066G281-30C Replacement Lighthead

PDF IconWhelen Micron Automotive Warranty Information
